Phase II Ultrasonic Thickness Gage - UTG-2600

Brand:

(No reviews yet) Write a Review
SKU:
UTG-2600

State of the art, digital tester is capable of reading wall thickness thru coatings and point without affecting the measurement and is packed with the most popular features including basic measurement, Scanning Capabilities, Adjustable Sound Velocity, extended memory and RS 232 output capabilities.
This dynamic sonic gauge is designed to measure the thickness of metallic and non-metallic materials such as steel, aluminum, titanium, plastics ceramic, glass and any other good ultrasonic wave conductor as long as it has parallel top and bottom surfaces.




Specifications:


Display type:
4-digit LCD w/back light
Min. display range:
0.003 (if>3.93", 0.0003"(if<3.93")
Measuring range:
Standard mode: 0.03-8.0"in steel
Thru coating mode: 0.118"-.905"
3.0-23mm w/standard probe
Accuracy: ±1%x H + 0.0007"
(H=displayed value)
Sound veocity range:
3280-32805ft/s (1000-9999m/s
Operating temperature: 32-122º
Frequency: 4MHz
Update range: 4Hz
Memory: 500 test values
Output: RS 232
Power supply:
3V AA Alkaline batt. (2pc)
Battery life:
Approx. 100 Hours. (w/backlight off)
Power consumption:
Working current is less than 3V
Dimensions:
5.86"x 2.87"x 1.25" (149x 73 32mm)
Weight: 5.6 oz. (160g)

Ultrasonic Thickness Gage
