Kent Manual Engine Lathe - KLS-1860V

Brand:

(No reviews yet) Write a Review
SKU:
KLS-1860V

Kent USA

Kent Manual Engine Lathe - KLS-1860V

  • 7.5 HP main spindle motor, 2 speed ranges with infinitely variable speed
  • D1-8 camlock, 3.1” spindle bore
  • Hardened and ground gears and bedways
  • Jog button, multi-position feed stops
  • Inch dials and leadscrews
  • Centralized lube system in headstock
  • Safety Foot brake

Standard Accessories

  • 3-jaw chuck (10”), 4-jaw chuck (10”)
  • Face plate (16”),Steady rest (3.5”), Follow rest (1-3”)
  • 4-way tool post, thread chasing dial
  • Coolant system, Full length splash guard
  • Worklight, standard tools

Optional Accessories

  • DRO system (Acu-Rite, Newall, etc.)
  • DRO installation charge
  • Aloris CA #4-set (tool post plus 6 bars)
  • 5C lever style collet closer
  • Royal spindle type live center (M.T. #5)
  • BTC 3-jaw chuck w/back plate (Zero-set, 10” D1-8)
  • BTC 3-jaw chuck w/back plate (Zero-set, 12” D1-8)
  • Taper turning attachment
  • Rustlick coolant (1 gallon, mixes 1:30)
Model KLS-1860V
Swing Over Bed

 18"

Swing Over Cross Slide  10.8"
Swing Over Gap  27.5"
Width of Bed  13"
Distance Between Centers  60"
Cross Slide Travel  11"
Top Slide Travel  4"
Spindle Speeds  2
Spindle Speed Range  200-2000 RPM
Through Hole Diameter  3.2"
Spindle Nose  D1-8 Camlock
Spindle Bore Taper  MT#7 with sleeve
Standard (Whit-Worth)  62 (1-5/8 to 72) tpi
Metric Pitch  28 (0.5 to 20) mm
Longitudinal Feeds  0.0015"-0.0913"
Cross Feeds  0.0006" - 0.0365"
Leadscrew Diameter  1-9/16"
Thread Pitch  4 TPI
Quill Travel  5"
Quill Diameter  3"
Quill Bore Taper  MT#5
Main Motor  7.5 HP (3 Phase)
Coolant Pump Motor  1/8 HP (3 Phase)
Overall Dimensions  112" x 40" x 50"
Weight   6380 lbs.
Kent Manual Engine Lathe
