ACER Supra Mini CNC Bed-Mill with Fagor 8055i/A CNC Control - E-1054B-4

Brand:

(No reviews yet) Write a Review
SKU:
E-1054B-4

ACER Supra Mini CNC Bed type Milling Machine with "Fagor 8055i/ A-MC" 4 Axis CNC Control

Bed-mill 1050 w/ 8055 4-Axis CNC Control (10" x 54" Table Size)


HIGH EFFICIENCY * PRODUCTIVITY * USER-FRIENDLY


THE PACKAGE INCLUDES:

  • ACER E-mill™ Mini Bedtype Milling Machine
  • “FAGOR” 8055i / A-MC 3 or 4-Axis CNC Control
  •  Auto Lube System
  • C5 Ball Screws and Double-End Thrust Bearing Set


ULTRA HIGH QUALITY ACER E-MILL™ MILLING MACHINE:

  • 5 HP Spindle Inverter Motor
  • 0 - 3,650 RPM Speed TOSHIBA VECTOR AC Frequency Drive
  • HRC 52° Hardened and Ground Table
  • Turcite-B Coated Slideway and Gibs
  • Precision Spindle w/ ABEC-7 Bearings
  • Meehanite Casting
  • Automotive Paint
  • Rugged 10” x 50” Table Size (10” x 54” option)
  • 1-1/4” Diameter Ball Screws with Casted Mounting Brackets
  • Hardened & Ground X, Y, & Z, Table Top and Bottom to HRC 52°
  • X, Y, Z Travel: 27.5” x 20” x 20.87” on Bed-mill 1050 (31.5” x 20” x 20.87”on Bed-mill 1054)
  • CAT #40 Taper Spindle
  • Class 7 Precision Spindle Bearings
  • Precision 4” Diameter Hard Chromed Quill at HRC 62°
  • Turcite-B Lining Saddle Ways to Reduce Slide-Way Wear
  • Max. Load on Table is 1,320 lbs.
  • Machine Weight: 4,609 lbs. on Bed-mill 1050 (4,758 lbs. on Bed-mill 1054)


CONTROL SOFTWARE FEATURES:

  • Interactive ICON based conversational programming system.
  • One screen—One Operation, Fill in the blanks & press cycle to start.
  • No Limit to the number of programs in memory!
  • Built-In Mini CAD/CAM system.
  • 11” Color TFT LCD screen.
  • Numerous Canned Cycles in Conversational and G-code.
  • (3) 36 in/lb. AC Brushless Servo Motors & Drives.
  • Flash memory (1MB flash ram / 512MB CF); 2GB CF optional ($1,500)
  • USB Memory port standard. Ethernet optional. ($700)
  • WinDNC (DXF converter) and Engraving.
  • Smart Z-axis quill for CNC and manual mode with scale-fed DRO feedback.
  • Full CNC package includes Ball Screws and Motor Brackets for all axes.
  • “FAGOR” 8055i / A-MC CNC’s give you 4th-axis capability out of the box!!


OPTIONAL ACCESSORIES: (Please Call/Contact Us for below Accessories)

  • Programmable RPM for 3-Axis Control
  • Remote Manual Pulse Generator
  • Remote Start / Stop Switch
  • Z-Axis D.R.O. Feedback
  • Home Position Switch for Home & Fixture Offset
  • Maxi-Torque Automatic Air Power Draw Bar & Safety Ring
  • Installation Fee on Power Draw Bar & Safety Ring
  • 12” Rotary Table (vertical & horizontal)
  • T-Slot Cover
  • Chip Pan
  • Clamping Kits (52 pieces)
  • 6” Angle Lock Milling Vise
  • Halogen Work Light
  • Coolant System
  • Installation Fee on Coolant System
  • Upgrade Frequency Inverter ( 3 Phase, 400V - 460V)
  • Upgrade Frequency Inverter ( 3 Phase, 380V - 520V)
Bed-mill 1050 w/ 8055 4-Axis CNC Control (10" x 54" Table Size)
