Baileigh PL-1860E-1.0 Metal Lathe with DRO, 18" Swing, 60" Length - BA9-1016624

Looking for a big, economical toolroom lathe? Look no further than the PL-1860E large metal lathe. It includes a DROpolished slideways, and a cast iron base—features you won't find on many machines in this price range.

  • 12 spindle speeds from 25 to 1,800 rpm.
  • 7.5 hp motor runs on 220-volt 3-phase power.
  • Perfect for shops or schools that need more capacity on a budget.
  • No assembly required.
  • 2-axis digital readout (DRO) system.
  • All of the ways are precision ground, hardened, and then polished to ensure smooth movement.
  • Cross-ribbed bed adds strength and stability.
  • Cast iron and sheet steel base supports the main frame and will stand up to years of use.
  • Gap lathe design allows you to remove a section of the slide for slightly more diameter.
  • Comes standard with:
    • 3-jaw universal chuck (8") and 4-jaw chuck (13").
    • Headstock chuck guard with automatic safety switch.
    • 8" back plate.
    • Steady rest and follow rest.
    • Emergency foot brake.
    • Integrated coolant system with rear splash guard.
    • Halogen work light.
  • Covered by a 1-year parts warranty.
  • Lifetime technical support by phone: you can call Baileigh's team of metalworking experts for as long as you're using this lathe.

Specifications:

Part Number PL-1860E-1.0
Stock Number BA9-1016624
Spindle Speeds 25-1800 rpm
Longitudinal Feed Imperial (qty / type) 122 / .0015"-.0913" / rev.
Speed Number 12
Spindle Bore 3.125"
Motor 7.5 hp
Spindle Nose D1-8
Threads Diametrical Qty Type 45 / 3-1/2 to 96 D.P
Threads Imperial Qty Type 61 / 1-5/8 to 72 T.P.I
Threads Metric Qty Type 24 / .5-20mm Pitch
Threads Module Qty Type 21 / .25 to 10 M.P
Spindle Taper Sleeve MT5
Spindle Taper Nose MT7
Tailstock Quill Taper MT5
Tailstock Quill Travel 6"
Compound Rest Travel 5-1/8"
Center Length 60"
Bed Width 13-1/8"
Main Motor 7.5 hp
Lead Screw Diameter 1.125"
Lead Screw Thread Pitch 4 T.P.I.
Max. Swing Over Bed 18"
Max. Swing Over Cross Slide 10-3/4"
Max. Swing In Gap Dia 27.5"
Cross Slide Travel 10-1/2"
Power 220V / 3-phase
Shipping Weight 5650 lbs
Shipping Dimensions 116" x 45" x 66"
