Baileigh PL-1236E-1.0 Metal Lathe, 12" Swing, 36" Length - BA9-1016616

The PL-1236E is a great metal lathe for anyone that is looking an economical lathe that is high in quality and features. Like all Baileigh Industrial lathes, the PL-1236E gear head metal lathe has an integrated gear system that allows for taping, turning, and polishing with a range of speeds from 70 to 1400 RPM. The PL-1236E is built to last with only top quality components and all ways are ground and hardened to ensure long life.

The Baileigh Industrial PL-1236E metal lathe is powered by a 220v system. As far as entry level metal lathes go, this one has all the features of the more expensive models. The included accessories are, three and four jaw chucks, steady rest, follow rest, face plate, live center, foot brake, coolant system, and halogen work light.

This economical gear-head metal lathe is a perfect choice for schools, hobbyists, and maintenance shops. The PL-1236E includes a quick-change tool post and 2 chucks.

  • 70 to 1,400 rpm variable speed.
  • Integrated gear system allows for taping, turning, and polishing.
  • All ways are ground and hardened to ensure long life.
  • Runs on 220-volt single-phase power.
  • Ability to cut standard and metric threads.
  • Quick-change tool post helps you save time.
  • 3-jaw and 4-jaw chucks can hold both square and rounded materials.
  • Steady rest and follow rest brace the shaft and prevent wobbling to ensure high accuracy.
  • Facing plate lets you shape materials that are large but not long. Bolt your metal to the plate to keep it square and symmetrical.
  • Coolant system consists of a reservoir and pump in the base plus a hose you can point as needed.
  • Foot brake helps keep your shop safe.
  • Halogen work light comes standard.
  • Covered by a 1-year parts warranty.
  • You can count on lifetime technical support by phone from Baileigh's team of reps with first-hand metalworking experience.

Specifications:

Part Number PL-1236E-1.0
Stock Number BA9-1016616
Sleeve Travel 4"
Spindle Bore 1.50"
Spindle Bore Taper Morse #5
Sleeve Taper Morse #3
Sleeve Diameter 1.250"
Range of Inch Threads 4 - 56 T.P.I.
Spindle Nose D1-4"
Travel of Cross Slide 5.312"
Travel of Top Slide 3.250"
Width of Bed 7.125"
Spindle Speed 9 (70 – 1400 rpm)
Swing Over Bed 12"
Swing Over Cross Slide 7.625"
Longitudinal Feed Range 0.002" – 0.0548"/rev
Lead Screw Thread Pitch 8 T.P.I.
Max. Tool Selection .625" x .625"
Cross Feed Range 0.007" – 0.0187"/rev
Distance Between Centers 36"
Power 220V / 1-phase
Shipping Weight 1395 lbs
Shipping Dimensions 69" x 44" x 64"
