Scotchman Dual Operator, Fully Integrated 8514-20M Ironworker

Standard Features
  • Dual Operator allows for Two Operators to Work at the Same Time at Full Capacity
  • 85 Ton Punch Station (1-1/16" in 1")
  • Keyed Punch Ram for Safety
  • 14" Throat Depth
  • Punch Gauging Table with Fence and Scale
  • Die Holder Complete with 2" Die Insert for #82 Dies, Punch Nut with Wrench
  • Adjustable Swing-Away Stripper
  • One Round Punch & Die: Max. Dia. 1-1/4"
  • Punch Jog Control
  • Two Adjustable Electric Stroke Controls with Scale
  • Two Electric Remote Foot Pedals
  • Two 2-Stage Hydraulic Pumps
  • Two Valves
  • 6" x 6" x 1/2" Slug-less Angle Shear
  • Built-In Rectangle Notcher: 2" x 4" x 1/2" can be converted to 3" x 3" V-Notcher, 50-Ton Punch Station, and 6" Open End Brake
  • 20" Flat Bar Shear with 4-Way Reversible Blade (1" x 16", 3/4" x 20")
  • Shear Table with Miter Fence
  • Rod Shear: 1/2", 3/4", 1", 1-1/2" Round and 1-1/2" Square
  • Slug Receptacles
  • Electrical Box Supplied with Emergency Palm Button and Lock-out Tag-out Accommodations
  • 230 or 460 Volt /3 ph Electrics
  • All Guards Necesary to Comply with ANSI B 11-5 Standards
  • Forklift Accommodations
  • Warranty: Three Years
  • Made in USA
  • For Optional Standard Tooling please Contact Us
Capacities & Specifications
Rated on: 65,000 PSI Tensile A 36 Mild Steel
Punching Capacity

85 ton
1-1/16" in 1"
77 mt
27 mm in 25 mm
Special Tooling 4" Max. Dia. 200 mm Max.
Throat Depth 14" 350 mm
Flat Bar Shear

20" Length
1" x 16"
3/4" x 20"
500 mm
25 mm x 400 mm
19 mm x 500 mm
Angle Shear 90° 6" x 6" x 1/2" 150 mm x 150 mm x 13 mm
(45° with Bar Shear) 4" x 4" x 1/2" 100 mm x 100 mm x 13 mm
Brake 12" 85 ton 77 mt
Brake 24" 85 ton 77 mt
Open End Brake 6" x 5/8" 150 mm x 16 mm
Pipe Notcher
Schedule 40 I.D.
3/4"
1"
1-1/4"
1-1/2"
2"
19 mm
25 mm
32 mm
38 mm
50 mm
90° V. Notcher
(Punch Station)
6" x 6" x 5/16" 150 mm x 150 mm x 8 mm
Rectangle Notcher 2" x 4" x 1/2" 50 mm x 100 mm x 13 mm
90° V. Notcher (Notcher Station) 3" x 3" x 1/2" 75 mm x 75 mm x 12 mm
Punch Attachment
(Notcher Station)
Throat Depth w/Punch Attachment
50 ton
1-1/4" in 1/2"
4-7/16"
32 mm in 12 mm
Channel Shear 2" to 6" 50 mm to 150 mm
Rod Shear
Round Rod (Max.)



Square Rod (Max.)

1/2"
3/4"
1"
1-1/2"
1-1/2"

13 mm
19 mm
25 mm
38 mm
38 mm
Square Tube Shear 1/2" to 2"
12 ga.
12 mm to 50 mm
2.75 mm
Picket Tool


1/2"
3/4"
1"
16 gauge
13 mm
19 mm
25 mm
1.6 mm
Offset Die Holder Max. 40 ton 36 mt
Strokes per Minute in Light Material 1/4" Stroke [Punch Station] 48 spm
Strokes Per Minute in Heavy Material 3/4" Stroke [Punch Station] 20 spm
Hydraulics 3,200/3,800 psi 220/260 bar
Motors Standard

10 hp 3 ph
230/460
208/380/575
7.46 kW
Motor Optional

10 hp 1 ph
230v
7.46 kW
Dimensions

W-30"
L-70"
H-77"
W-750 cm
L-1500 cm
H-1925 cm
Weight 5,400 lbs 2455 kg
Dual Operator, Fully Integrated with 5 Fixed Tool Stations
