Mitutoyo 14" Horizontal Optical Comparator Profile Projector - 172-810-10A

Brand:

(No reviews yet) Write a Review
SKU:
172-810-10A

Mitutoyo

Mitutoyo 14" Horizontal Optical Comparator Profile Projector - 172-810-10A

  • Bench-top model that uses horizontal optical system.
  • Suitable for thread pitch measurements—blurred or distorted images will not be produced when workpiece is angled.
  • Inverted image on the day-bright screen.
  • 14" (356mm) diameter vernier protractor screen with solid line cross-hairs for easy alignment.
  • Heavy-duty workpiece table incorporates linear scales for fast, accurate measurement.
  • The PH-A14’s generous X, Y workstage travel (8”x 4”) provides users with ample range to cover application needs.
  • New location of the Y-axis handle improves ease of operation.
  • The workstage provides high accuracy and can handle a workload of up to 100 lbs.
  • Fiber illuminator is standard accessory.


For Mitutoyo 14" Optical Comparator, Profile Projector & Accessories Click Here

Mitutoyo 14" Horizontal Optical Comparator Profile Projector - PH-A14
