Trico MD-1200 Micro Drop Dispenser, 1 Line Model 30801 - 85-520-691

Brand:

(No reviews yet) Write a Review
SKU:
85-520-691

Trico

Trico MD-1200 Micro Drop Dispenser, 1 Line Model 30801


The MD-1200 Micro-Drop Dispenser provides a cost effective solution when flood cooling is impractical or unavailable. When used in milling, tapping, and sawing applications, the MD-1200 dispenses small amounts of Micro Drop Synthetic or Vegetable based lubricant. Compared to flood cooling, there is no coolant sump to maintain or used coolant to dispose of.


Solenoid versions allow these units to be interfaced with CNC controls or other signaling devices. The pressurized delivery system of the MD-1200, provides instant on/off performance when used with the solenoid control.


High energy nozzle design eliminates fogging for cleaner environment & greater chip clearing power, allowing faster feeds & speeds


Features:

  • Individual, high resolution, air and liquid controls offer flexibility, in different set-ups
  • Independent line adjustment
  • Positive pressure design gives instant fluid delivery for faster cycle times
  • Lifetime warranty on manufacturing defects


Specifications:

BRAND TRICO
MODEL # 30801
NO. OF LINES 1
LENGTH OF LINE 6'
STYLE 1 Line - Manual On/Off
TYPE Micro-Drop® Dispenser
AIR CONSUMPTION 1.7 CFM/line
AIR INLET SIZE 1/4" NPT
DELIVERY LINE LENGTH 6'
INLET AIR PRESSURE 60-125 PSI
LIQUID FLOW RANGE 2 - 16 drop/minute
LIQUID VISCOSITY 50 - 200 SUS
NOZZLE TYPE 18"Loc-Line®
PRICE TABLE DESCRIPTION 1 Line, Manual On/Off
RECOMMENDED FILTER STRENGTH 40 micron
WEIGHT 20 lbs.
COUNTRY OF ORIGIN UNITED STATES OF AMERICA
TRICO MD-1200 Micro-Drop Dispenser, Model 30801, 1 Line
