Trico DL Magnum Spray Cooling System, 1/4 NPT
The DL Magnum Spray Cooling System provides cooling solutions for light duty machining and tool room applications. This dispenser is easy to install requiring only shop air and dropping the siphon line into a coolant tank.
Features:
- Siphon delivery system
- 15 in. heavy duty metal nozzle conduit
- Advanced nozzle design for increased chip clearing power and reduced overspray
- Independent air and liquid controls
- 6 ft. coolant pickup line with stainless steel filter
- Sturdy 60 lb. mounting magnet
- Check valve minimizes delay of fluid upon start-up
- BSPT threads are available
DL Magnum Spray Cooling Systems are designed to be used with a water-soluble coolant such as TC-1 Premium Synthetic Coolant.
Specifications:
| Valve Body | Plated Brass |
| Seals | Buna-N |
| Siphon Line | Polyurethane |
| Filter Element | 40 x 40 Mesh Stainless Steel |
| Pressure | 60-120 PSI |
| Air Inlet | 1/4" NPT |
| Fluid type | Water based coolants suitable for spray cooling |
