SPI Indicator Points & Kits for AGD Dial Indicators

Indicator Points for AGD Dial Indicators

  • Each point is carefully manufactured of highest quality steel
  • 4 - 48 Threads for use in AGD 1, 2, 3, 4 indicators


Specifications:

Part Number 14-715-7 14-716-5 51-100-6
Type Select-A-Point Kit Select-A-Point Kit Extension Kit
Number of Pieces 6 6 3
AGD Group No. AGD 1, 2, 3, 4 AGD 1, 2, 3, 4 AGD 1, 2, 3, 4
Description Flat (M) & (L)
Ball End (B) & (D)
Conical (G)
& 1" Extension (W) Kit
Flat (K)
Ball End (I) & (C)
Conical (H)
& Stems (S) & (V) Kit
Extension Kit:
Extensions 1", 2" & 3"
Contents 0.750
0.875 Flat
0.395
0.625 Ball
0.750 Conical
1" Extension
0.895 Flat
0.875
0.825 Ball
0.875 Conical
0.821
0.312 Stems
Extensions:
1", 2", 3"
Point Length (Decimal Inch) 0.750
0.875
0.395
0.625
0.750
1.00
0.895
0.875
0.825
0.875
0.821
0.312
1"
2"
3"



* Button & flat bottom dimensions are diameters not lengths
+ Wire end is about 1/4" long larger dia. stem is about 5/16" long
^ Wire end is about 7/64" long larger dia. stem is about 37/64" long
~ Female inch #4 - 48, Male metric M2.5 x 0.45
