Adam PTS Pallet Truck Scale - PTS5000a

Brand:

(No reviews yet) Write a Review
SKU:
PTS5000a

Adam Equipment

Adam PTS Pallet Truck Scale - PTS5000a


Speed up warehouse operations and reduce transportation overcharges with the PTS


Designed for commercial and industrial use, the PTS pallet truck scale has steel pallet forks, non-marring wheels and a zero-radius pivoting handle. Its sleek, solid design facilitates the transport of items from one place to another in warehouses, shipping departments or on production floors.


Included with the PTS is the AE 402 indicator, which is IP66 rated for protection against water and dust. The indicator offers a wide range of features and functions to provide fast, accurate results, including an RS-232 interface for quick connection to computers or printers.


Hardware Features:

  • Color-coded keys facilitate quick recognition of the most frequently used buttons
  • RS-232 interface is available to provide speedy connection to computers and printers
  • Splash-proof housing, keypad and display are easy to clean
  • Wheels swivel, allowing easy movement


Software Features:

  • Audible overload alarm warns when capacity is exceeded
  • Checkweighing with audible alarm
  • External calibration allows for verification and adjustment with weights
  • Parts counting with preset sample sizes
  • Selectable auto-clear function enables the last item to be reset each time the scale returns to zero
  • Selectable digital filtering for animal/dynamic weighing enables consistent results for moving subjects
  • Zero-tracking feature ensures display returns to zero reading


Display Features:

  • Vivid, backlit LCD easily visible in any lighting conditions
  • Programmable backlight can be set to "always on," "always off" or "light only when weighing"
  • Capacity tracker built into display for easily monitoring possible overloads
  • Checkweighing LEDs light to clearly show under, over and acceptable limits


Power Features:

  • Rechargeable battery included for operation almost anywhere
  • Programmable auto power-off to save energy
  • AC adapter included


Applications:

  • Weighing
  • Parts counting
  • Percentage weighing
  • Checkweighing
  • Dynamic / animal weighing


Specifications:

Capacity 5000 lbs / 2000 kg
Readability 1 lb / 0.5 kg
Repeatability 2 lb / 1 kg
Weighing Units kg, lb, lb:oz, oz, N
Stabilization Time 2.0
Pan Size 6.3" x 47.2" / 160 x 1200 mm
Linearity 2 lb / 1 kg
Power Supply 12VDC 800mA adapter / Internal rechargeable battery
Construction Mild steel base
Interface RS-232
Operating Temperature -10° to 40°C / 14° to 104°F
Display Digit Height 1.6" / 40mm
Battery Life (Hours) 90
Overall Dimensions 27.2" x 62.2" x 46.5" / 690 x 1580 x 1180 mm (W x D x H)
Net Weight 275.5 lbs / 125 kg



Click to see all accessories for the Adam PTS Pallet Truck Scale
