Proxxon Engraving Device GE 20

Brand:

(No reviews yet) Write a Review

Proxxon

Proxxon Engraving Device GE 20

  • For engraving letters, numbers and individual shapes in metal, plastic, glass or stoneware.
  • For name plates, jewellery or other objects of value. Also for working with self-made stencils or commercially available templates (plants, animals, coats of arms). For small size, individual shapes, cut-outs or outline shapes, even in series.
  • A maximum of 14 characters can be fastened in the guide bar (template holder). Template contours are precisely to be followed using the guide marker (ball handle).
  • The lettering to be milled is scaled down during transfer. The transfer ratio can be set to 2:1, 3:1, 4:1 or 5:1 by simple adjustment of two screws.
  • The work piece is aligned and fixed on the movable guide block by means of clamping jaws (here MICROMOT clamping jaws set NO 24 256) or using a vice.

Scope of delivery:
2 sets of letters from A to Z, hyphen, full stop and dash (total 52 pieces), one each Allen key 1.5 - 3.0 and 5. 0mm as well as a HEX (ball head) screwdriver 2.5mm. Includes a detailed instruction manual.
Note:
Professional drill/grinder IBS/E and clamping jaws are not included in the scope of delivery.

For Proxxon GE 20 Manual CLICK HERE
