Palmgren Dual Force Multi-Function Precision Machine Vises

  • Model 9625932 is standard with the traditional push style moveable jaw
  • Model 9625933 is standard with a pull style moveable jaw. This configuration provides an added benefit of easier part programming in the “Y” axis. It also reduces the reach-over distance, making part loading and unloading safer and easier for the machine operator.
  • The vises can be mounted on its base/bottom, on either side or upright. They can also be mounted back to back to create a fast, easy and economical vise tombstone.
  • 0.0005 ̋ clamping repeatability
  • Bed heights matched to +/- 0.0004 ̋
  • Parallelism of keyways on bottom of vise bed
to the jaw face +/- 0.0008 ̋
  • Equipped with Dual Force anti-lift mechanism
  • 80,000 PSI ductile iron castings
  • LIFETIME GUARANTEE
