Mitutoyo Surface Roughness Tester Surftest SJ-310

  • The handheld data processing unit and the 5.7-inch color graphic LCD touch-panel provide superior readability and operability. The LCD also includes a backlight for improved visibility in dark environments.
  • The excellent user interface provides intuitive and easy-to-understand operability.
  • Complies with the following standards: JIS (JIS-B0601-2001, JIS-B0601-1994, JIS B0601- 1982), VDA, ISO- 1997, and ANSI.
  • The Measure-Start and other frequently used buttons are strengthened to resist wear and the detrimental effects of workshop contaminants.
  • Equipped with a large-capacity battery allowing approximately 1500 measurements when fully charged.
  • Includes convenient carrying case for protection in the field.
  • A high-speed printer is built into the main unit. Either landscape or portfolio mode can be selected according to the application. Paper saving mode is supported.
  • The display interface supports 16 languages, which can be freely switched.
  • 10 sets of measurement conditions can be saved in the measurement unit–an optional memory card can save measurement conditions and the measured profile.


Specifications:

Order No. 178-571-01 178-571-02 178-573-01 178-573-02 178-575-01 178-575-02
Drive Unit Standard
type
(178-230-2)
Standard
type
(178-230-2)
Retractable
type
(178-235)
Retractable
type
(178-235)
Transverse
tracing type
(178-233-2)
Transverse
tracing type
(178-233-2)
Detector 0.75mN
type
(178-296)
4mN
type
(178-390)
0.75mN
type
(178-296)
4mN
type
(178-390)
0.75mN
type
(178-387)
4mN
type
(178-386)
Display Unit Standard type with printer
Detector:
Conical taper angle
60° 90° 60° 90° 60° 90°
Stylus Tip Radius 2µm 5µm 2µm 5µm 2µm 5µm
Detector
measuring force
0.75mN 4mN 0.75mN 4mN 0.75mN 4mN
