Mitutoyo Quickmike 0-1.2"/0-30mm - 293-676

Brand:

(No reviews yet) Write a Review
SKU:
293-676
Range:
0-1.2"/0-30mm
Resolution:
.00005"/.001mm
Type:
Standard

Mitutoyo

Mitutoyo Quickmike 0-1.2"/0-30mm  - 293-676

An extremely rapid action, water-resistant Mitutoyo digital micrometer that enables measurements to be made many times faster than a standard micrometer. ABSOLUTE System scale for error free, high-speed measurement. The frame incorporates a heat shield to preserve accuracy over extended measuring sessions. A ratchet thimble guarantees repeatable measurement. SPC data output.

  • Type Standard
  • Range 0-1.2"/0-30mm
  • Actual Range 0-30.48mm / 0-1.2"
  • Resolution 0.001mm / .00005"
  • Accuracy ±2µm / ±.0001"
  • Data Output Yes
  • Display LCD
  • Flatness 0.3µm / .000012"
  • Measuring Faces Carbide
  • Parallelism 2µm / .00008"
  • Protection IP54
  • Battery SR44
  • Battery Life Approx. 1.2 years under normal use
  • Functions Origin-set, Zero-set, Inch/mm, Data Hold, Automatic Power On/Off, Data Output, Low Voltage alarm, Counting Value Composition Error alarm
  • Non-rotating spindle and the new ratchet friction thimble.
  • Speedy spindle feed of 10mm/rev.
  • ABSOLUTE System linear scale.
  • IP54 dust/water protection (when not connected with data output cable).
  • SPC data output.



Quickmike 0-1.2"/0-30mm
