Mitutoyo Inch Rectangular Gage Block Sets Series 516

Brand:

(No reviews yet) Write a Review

Mitutoyo

Mitutoyo Inch Rectangular Gage Block Sets Series 516


** CERA blocks are adopted for frequently-used blocks.


81-block set: All are CERA blocks. Except 2", 3", and 4" are Steel blocks


Specifications:

#Blocks Order No Material Grade Included Blocks
81     516-301-26     CERA     00     9 Blocks =.1001-.1009 Step=.0001
49 Blocks =.101-.149 Step=.001
19 Blocks =.05-.95 Step=.05
4 Blocks =1-2-3-4-100 Step=1
81     516-302-26     CERA     0     9 Blocks =.1001-.1009 Step=.0001
49 Blocks =.101-.149 Step=.001
19 Blocks =.05-.95 Step=.05
4 Blocks =1-2-3-4-100 Step=1
81     516-302-27**     Steel/CERA     0     9 Blocks =.1001-.1009 Step=.0001
49 Blocks =.101-.149 Step=.001
19 Blocks =.05-.95 Step=.05
4 Blocks =1-2-3-4-100 Step=1
81     516-303-26     CERA     AS-1     9 Blocks =.1001-.1009 Step=.0001
49 Blocks =.101-.149 Step=.001
19 Blocks =.05-.95 Step=.05
4 Blocks =1-2-3-4-100 Step=1
81     516-304-26     CERA     AS-2     9 Blocks =.1001-.1009 Step=.0001
49 Blocks =.101-.149 Step=.001
19 Blocks =.05-.95 Step=.05
4 Blocks =1-2-3-4-100 Step=1
35       516-313-26       CERA       00       1 Block =.10005 Step=
9 Blocks =.1001-.1009 Step=.0001
9 Blocks =.101-.109 Step=.001
9 Blocks =.11-.19 Step=.01
3 Blocks=.1-.3 Step=.1
4 Blocks=.5,1,2,4
35       516-314-26       CERA       0       1 Block =.10005 Step=
9 Blocks =.1001-.1009 Step=.0001
9 Blocks =.101-.109 Step=.001
9 Blocks =.11-.19 Step=.01
3 Blocks=.1-.3 Step=.1
4 Blocks=.5,1,2,4
35       516-315-26       CERA       AS-1       1 Block =.10005 Step=
9 Blocks =.1001-.1009 Step=.0001
9 Blocks =.101-.109 Step=.001
9 Blocks =.11-.19 Step=.01
3 Blocks=.1-.3 Step=.1
4 Blocks=.5,1,2,4
35       516-316-26       CERA       AS-2       1 Block =.10005 Step=
9 Blocks =.1001-.1009 Step=.0001
9 Blocks =.101-.109 Step=.001
9 Blocks =.11-.19 Step=.01
3 Blocks=.1-.3 Step=.1
4 Blocks=.5,1,2,4
81     516-549-56     Steel     K     9 Blocks =.1001-.1009 Step=.0001
49 Blocks =.101-.149 Step=.001
19 Blocks =.05-.95 Step=.05
4 Blocks =1-2-3-4-100 Step=1
35       516-550-56       Steel       K       1 Block =.10005 Step=
9 Blocks =.1001-.1009 Step=.0001
9 Blocks =.101-.109 Step=.001
9 Blocks =.11-.19 Step=.01
3 Blocks=.1-.3 Step=.1
4 Blocks=.5,1,2,4
81     516-557-56     CERA     K     9 Blocks =.1001-.1009 Step=.0001
49 Blocks =.101-.149 Step=.001
19 Blocks =.05-.95 Step=.05
4 Blocks =1-2-3-4-100 Step=1
35       516-558-26       CERA       K       1 Block =.10005 Step=
9 Blocks =.1001-.1009 Step=.0001
9 Blocks =.101-.109 Step=.001
9 Blocks =.11-.19 Step=.01
3 Blocks=.1-.3 Step=.1
4 Blocks=.5,1,2,4
81     516-901-26     Steel     00     9 Blocks =.1001-.1009 Step=.0001
49 Blocks =.101-.149 Step=.001
19 Blocks =.05-.95 Step=.05
4 Blocks =1-2-3-4-100 Step=1
81     516-902-26     Steel     0     9 Blocks =.1001-.1009 Step=.0001
49 Blocks =.101-.149 Step=.001
19 Blocks =.05-.95 Step=.05
4 Blocks =1-2-3-4-100 Step=1
81     516-903-26     Steel     AS-1     9 Blocks =.1001-.1009 Step=.0001
49 Blocks =.101-.149 Step=.001
19 Blocks =.05-.95 Step=.05
4 Blocks =1-2-3-4-100 Step=1
81     516-904-26     Steel     AS-2     9 Blocks =.1001-.1009 Step=.0001
49 Blocks =.101-.149 Step=.001
19 Blocks =.05-.95 Step=.05
4 Blocks =1-2-3-4-100 Step=1
35       516-913-26       Steel       00       1 Block =.10005 Step=
9 Blocks =.1001-.1009 Step=.0001
9 Blocks =.101-.109 Step=.001
9 Blocks =.11-.19 Step=.01
3 Blocks=.1-.3 Step=.1
4 Blocks=.5,1,2,4
35       516-914-26       Steel       0       1 Block =.10005 Step=
9 Blocks =.1001-.1009 Step=.0001
9 Blocks =.101-.109 Step=.001
9 Blocks =.11-.19 Step=.01
3 Blocks=.1-.3 Step=.1
4 Blocks=.5,1,2,4
35       516-915-26       Steel       AS-1       1 Block =.10005 Step=
9 Blocks =.1001-.1009 Step=.0001
9 Blocks =.101-.109 Step=.001
9 Blocks =.11-.19 Step=.01
3 Blocks=.1-.3 Step=.1
4 Blocks=.5,1,2,4
35       516-916-26       Steel       AS-2       1 Block =.10005 Step=
9 Blocks =.1001-.1009 Step=.0001
9 Blocks =.101-.109 Step=.001
9 Blocks =.11-.19 Step=.01
3 Blocks=.1-.3 Step=.1
4 Blocks=.5,1,2,4
