Kent KGS-1020AHD Automatic Surface Grinder, 10" x 20" working capacity - KGS-1020AHD

Brand:

(No reviews yet) Write a Review
SKU:
KGS-1020AHD

Kent USA

Kent KGS-1020AHD Automatic Surface Grinder, 10" x 20" working capacity


Features:

  • 10" x 20" working capacity; flange mount spindle cartridge for superior side grinding rigidity
  • 3-axis automatic movement with incremental downfeed and electronic auto-crossfeed
  • Roller ball on linear table ways for smooth longitudinal movements with minimal maintenance
  • Double V precision hand scrapped turcite saddle ways for smooth and long lasting performance
  • High column extra rigid H-frame design with 21" spindle center to table for extra clearance under the wheel; Over size rear splash guard
  • Over 3,690 pound net weight for super vibration damping capability
  • Centralized automatic lubrication system
  • Safety 24V control circuit power


Standard Accessories:

  • Grinding wheel
  • Wheel Flange
  • Wheel balancing base
  • Wheel balancing arbor
  • Diamond table dresser base & tip
  • Leveling bolts & pads
  • Work light
  • Toolbox with tools


Optional Accessories:

  • DRO system
  • Paper filter & magnetic separator coolant system
  • Permanent chuck
  • Dust-suction coolant system
  • Overhead parallel dresser
  • Extra wheel flange
  • Rustlick coolant


Specifications:

Model KGS-1020AHD
Table Travel 23.6"
Saddle Travel 11.4"
Working Capacity 10.4" x 21.4"
T-Slot 1 x 9/16”
Spindle Motor 3 HP
Spindle Speed 3500 RPM
Grinding Wheel 8" x 1/2" x 1-1/4"
Vertical Graduation 0.0005"
Vertical Revolution 0.100"
Auto Downfeed Increment 0.0001" 10 Steps
Spindle to Table 21"
Net Weight 3696 lbs.
Gross Weight 4246 lbs.
Kent Automatic Surface Grinder, 10" x 20" working capacity
