GrindoSonic HT System


GrindoSonic HT system for elevated temperature materials testing based on the Impulse Excitation Technique (IET)


GrindoSonic® HT is the reference solution for high temperature materials testing up to 1200°C, optionally with inert gas atmosphere.


Highlights:

  • Based on Industry standard GrindoSonic® measurement Technology
  • Fully programmable ramping/dwelling temperature profile
  • Programmable measurement intervals in 1 degree steps (ramp) or 1 second steps (dwell)
  • Data recorded for post processing and analysis
  • E-modulus is calculated according to ASTM-E1876 standard

Applications:

  • Metals and Alloys
  • Ceramics
  • and more...

Options:

  • Frequency analysis
  • FFT calculation for detections of multiple vibrations modes
  • Selection of zones of interest by waveband filtering
  • Oscilloscoop function for time domain analysis
  • Graphic visualisation of frequency domain


Technical Information:

  • Impulse Excitation Technique (IET) based measurement principle
  • Maximum working temperature of 1200°C
  • Optional up to 1500°
  • Minimum sample temperature at start: -200°C
  • Optional inert gas atmosphere


Features of the HT Unit:

  • Automated E-G calculation
  • Connected to MK7 unit with all the features coming from the MK7
  • E – modulus versus Temp. visualization
  • Visualization off: temperature vs Time
  • Frequency vs temperature
  • Modulus vs temperature
  • Pulsation adjustment
  • Time and Temperature adjustment
  • Industry standard Naberterm oven with all industrial approved regularizations (safety)
  • Tmax 1200 °C
  • Heating from two sides
  • Ceramic heating plates with integral heating element which is safeguarded against fumes and splashing, and easy to replace
  • Insulation made of non-classified fiber material
  • Housing made of sheets of textured stainless steel
  • Flap door which can be used as work platform
  • Exhaust air outlet in rear wall of furnace
  • Solid state relays provide for low noise operation
  • Delivery includes base, ceramic plunger with base plate in the furnace lining.
  • Process control
  • Number of programs 5 with controller unit B410 (standard Grindosonic)
  • Number of Elevated segments 4 with B410 (standard Grindosonic)

Optional:

  • Number of programs 10 with C540
  • Number of Elevated segments 20 with C540
  • Number of programs 50 with P480
  • Number of Elevated segments 40 with P480


Features of the MK7 Unit:

FFT "Fast Fourier Transform" / Spectroscope

  • Spectrum visualization between 20Hz and 150KHz
  • Extreme high resolution of up to 1ppm (1in 1.000.000)
  • Noise level adjustment
  • Sample size and frequency adjustment
  • Normalization function to rescale low energy

E-G Poison calculation

  • Automatic calculation of E and G modulus
  • Measurement of honing stones, bars, cylinders, grinding wheels...
  • USB memory stick connection
  • Full spectrum data storage (.csv)

Wave form visualization / oscilloscope

  • Adjustment in scale and time
  • Full waveform storage (.csv)
  • Time domain visualization of measurements

Filter band instrumentation

  • Eight high order hardware analog precision band pass filters (full instrumentation)
  • Software filter band selection

And more

  • Piezo vibration detector full ultra-high frequency range
  • Microphone vibration detector
  • High accuracy better than 0,005%.
  • Ease of use measurement system
  • Connection to an High Temperature oven is possible
  • Trigger level adjustable
  • Option: in color waterfall plot software for FFT analyses
  • Non - destructive measuring method
  • ASTM standards:
       - ASTM E1876, ASTM C1259, ASTM C1548, ASTM C215,
       - EN 843-2, EN ISO12680-1, EN 14146 and many more
