Drill Grinder 82-R Model TDR/SRD

Brand:

Call for Pricing

(No reviews yet) Write a Review

Drill Grinder 82-R Model TDR/SRD


82-R Increased Versatility

Same advantages as 80-M basic unit plus additional features for splitting points on standard or parabolic drills. Expandable features include tap and reamer resharpening using our 5C collet holder + indexing finger, your 5C collets

  • 82-R R.H. Drills 1/16"-13/16"
  • LHOP/R left-hand drill option 1/16"-1/2"
  • PBOPIR Point splitting option 1/8"-1/2"
  • TROP/R Tap-reamer option taps #10-3/4"reamers 1/8"- 3/4"


Customize point angles and clearances to achieve the most efficient feed rates for your job!

  • Dimensions 10"W x l6"L x 8"H
  • Weight 50 Lbs.
  • Cast iron, aluminum & steel 7 construction
  • Totally enclosed Baldor motor 1 10V or 230V
  • Hardened and ground slide rails
  • Drill size capacity and increased versatility varies with each model
  • Precise results
  • All models built to satisfy industrial quality
  • Drill point concentricity is .001"Lip to lip
  • Angle range 85 deg. to 160 deg.
  • Relief angles 0 deg. to 20 deg.
  • Sharpen high speed steel or carbide tooling
  • Shipped via UPS
  • Made in the USA


Grinding Range:

R.H. 1/16" - 13/16"

All machines come equipped to sharpen drills within the drill range specified.
(I.E. They come with the appropriate chuck and grinding wheel)
