Drill Grinder 82-B Model TDR/SRD
82-B Sharpens drills 1/16"-1-1/2"
Only two drill chucks span the entire drill range and designed to produce all the features of the Models 80-M & 82-R plus offering the convenience of refacing the face of endmills using our specially designed 5C collet holder + indexing finger, your 5C collets. Diamond wheels are available for each model.
- 82-B Model TDR/SRD Drill Grinder
- 82-B R.H. Drills l/16"-1-1/2"
- LHOP/B left-hand drill option 1/16"-l/2"
- PBOP/13 point-splitting option 1/8"-3/4"
- TROP/B tap-reamer option taps #10-1"reamers 1/8"-1"
- EMOP/B endmill refacing 3/16"-l"
- (*) includes, PBOP/B point splitting capability
Customize point angles and clearances to achieve the most efficient feed rates for your job!
- Dimensions 10"W x l6"L x 8"H
- Weight 50 Lbs.
- Cast iron, aluminum & steel 7 construction
- Totally enclosed Baldor motor 1 10V or 230V
- Hardened and ground slide rails
- Drill size capacity and increased versatility varies with each model
- Precise results
- All models built to satisfy industrial quality
- Drill point concentricity is .001"Lip to lip
- Angle range 85 deg. to 160 deg.
- Relief angles 0 deg. to 20 deg.
- Sharpen high speed steel or carbide tooling
- Shipped via UPS
- Made in the USA
Grinding Range:
R.H. Drills 1/16"- 1-1/2"
All machines come equipped to sharpen drills within the drill range specified.
(I.E. They come with the appropriate chuck and grinding wheel)
