Bison 4-Jaw (2pc) 20" A2-15 Independent Chuck Forged Steel Body, 8" Hole - 7-859-2043

Brand:

Bison 4-Jaw (2pc) 20" A2-15 Independent Chuck Forged Steel Body, 8" Hole - 7-859-2043
(No reviews yet) Write a Review
SKU:
7-859-2043
Bison 4-Jaw (2pc) 20" A2-15 Independent Chuck Forged Steel Body, 8" Hole - 7-859-2043

4-Jaw (2Pc) Independent Chuck Forged Steel Body, Extra Heavy Duty, 20in A2-15 8.0 Hole BISON-BIAL
4-Jaw Independent Extra Heavy Duty Chucks Standard Accessories:

  • 1 Set of two-piece master jaws
    (hard top jaws and hard master Jaws)
  • 1 Wrench
  • 1 Set of Mounting Bolts
  • 2 Allen keys
  • 1 Eye Bolt

Optional Accessories:

  • Hard top jaws
  • Chuck wrench with flat T-bar end
  • Chuck wrench for fast jaw movement
Chuck Diameter A in (mm) 20 (508.0)
Mount   A2-15
Chuck Jaws   2-piece
Maximum Speed RPM 1000
Weight lb (kg) 414 (188.1818)
Hole Diameter C in (mm) 8.0 (203.2)
B +.001 in 11.251
D in (mm) 13.000 (330.2)
G in (mm) 5.71 (145.0)
H in (mm) 6.067 (154.1)
I in (mm) 2.981 (75.7)
K in (mm) .866 (22.0)
L in (mm) 2.362 (60.0)
N in (mm) .748 (19.0)
E   M24x3
F in (mm) 1.340 (34.0)
d1 min in (mm) 1.77 (45.0)
d2 max in (mm) 19.68 (499.9)
Gripping Force, Wrench Torque NM   350
Gripping Force, Jaw lbs   7057
