Baileigh WJT-7839-HD Welding Jig Table - BA9-1010426

Brand:

(No reviews yet) Write a Review
SKU:
BA9-1010426

Baileigh

Baileigh WJT-7839-HD Welding Jig Table - BA9-1010426

Made from 250 Cast iron the WJT-7839-HD welding jig table from Baileigh Industrial is made to withstand the rigors of any shop. All of Baileigh Industrial's welding tables are made to exact tolerances and maintain flatness of +/- .0025" and have a hardness rating of 140 to 160 Brinell.

The WJT-7839-HD Welding Jig Table has a table size of 78" x 39" and has a total of 5 mourning surfaces that use Industry standard 28mm holes that are spaced at 100mm to ensure the most options with the strongest holding power.  For more information about our cast iron welding tables, contact a Baileigh representative.

  • 78" x 39" Industrial Welding Table with Holes
  • Made from 250 Cast Iron with nitride coating
  • Brinell Hardness 140~160
  • 5 Mounting Surfaces
  • Expandable
  • 2 ton weight capacity
  • Industry Standard 28mm Mounting holes
  • 100mm hole spacing
  • Etched Position Marks
  • Includes table Oiler, Brush and cleaning stone

Click to see the Welding Table Accessory Kit

Specifications:

Part Number WJT-7839-HD
Stock Number BA9-1010426
Working Table Size 78" x 39"
Table Load Capacity 2 Tons
Table Height 33.5"
Shipping Weight 1500 lbs
Table Flatness +/- .0025"
Number of Mounting Surfaces 5
Mounting Hole Size 28mm
Mounting Hole Spacing 100mm
Shipping Dimensions 89" x 41" x 13"
Dimensions L x W x H 80" x 45" x 45"
Baileigh WJT-7839-HD Welding Jig Table
