Baileigh R-M55H Hydraulic Roll Bender - BA9-1006859

This hardworking ring roller adds an industrial-grade hydraulic system to the many tried-and-true features from Baileigh's landmark R-M55.

  • This ring roller bender runs on 220-volt single-phase power.
  • Bends a maximum capacity of 2.75" round tube and 2" schedule 40 pipe.
  • Works with 3 rolls1 top forming roll and 2 driven bottom rolls.
  • You can operate the R-M55H in 2 positionsvertical, for small rolling projects, and horizontal (on its back) for longer sections of material.
  • Independent, easily-movable control pedestal lets you adjust the top roll's positioning and program stops.
  • Digital readout tells you the exact position of the top shaft to ensure simple repeatability for production runs.
  • Direct gearbox drive system delivers mighty full torque even when bending at full capacity.
  • Foot pedal control lets you conveniently switch between forward and reverse modes.
  • Variable-speed inverter allows you to adjust the rolling speed to suit you material and project.
  • Comes standard with roll sets that you can configure to suit many applications.
  • Constructed from heavy steel plate to maintain accuracy and minimize flex.
  • Baileigh covers this hydraulic roll bender with a 1-year parts warranty and lifetime technical support by phone.

Why choose the Profile Bender R-M55H over similar machines?

  • Hydraulic system controls top forming roll, ensuring precision and reducing the time and effort necessary to produce repeatable radii.
  • Rugged one piece framework adds to this roll bender's strength and ensures that it will deliver accurate results when bending at maximum capacity—for years!
  • Overload-protected Allen-Bradley inverter monitors rolling speed to extend the machine's use as long as possible.
  • Select an optional roll set to fit your application from Baileigh's wider line of tooling, stocked for quick shipment.
  • If you need troubleshooting or tips on a difficult project, you can call Baileigh's team of experienced reps for as long as you’re using the R-M55H.

Specifications:

Part Number R-M55H
Stock Number BA9-1006859
Roll Adjustment Hydraulic
Pipe Capacity Size: 2" (sch. 40) / Min. Dia.: 40"
Round Tube Capacity Size: 2.75" (.083") / Min. Dia.: 60"
Square Tube Capacity Size: 2" (.083") / Min. Dia.: 48"
Solid Round Capacity Size: 1.375" / Min. Dia.: 20"
Flat Bar Easy Way Size: 4" (.5") / Min. Dia.: 20"
Flat Bar Hard Way Size: 2.25" (.375") / Min. Dia.: 20"
Angle Iron Capacity Size: 2" (.250") / Min. Dia.: 28"
Shaft Diameter 1.968"
Shaft Center Distance 13.12"
Lower Roll Dia. 5.827"
Pinch Single
Power 220V Single Phase
Shipping Weight 965 lbs
Material Type All Specs based on 60,000 PSI (42 Kg/mm 2) Tensile Strength – Mild Steel.
*Optional Tooling Some applications may require optional tooling.
Please contact a Technical Sales Specialist at Baileigh Industrial with specific application details.
Shipping Dimensions (Inches) 60 x 44 x 77
