Baileigh PR-503 Hydraulic Plate Roll - BA9-1006531

The PR-503 plate bending roll is a true workhorse and a staple of the Baileigh Industrial line of plate rolls The PR-503 has a maximum 61" forming width, and can roll up to 3 gauge (1/4") mild steel sheet metal at that the full width. The PR-503 sheet metal roller is completely hydraulically driven for increased durability and reliability. All 3 rolls are driven on the PR-503 plate bending machine such that the operator can roll more material faster and increase the productivity of the shop.

For even more productivity, a digital readout is also standard on the PR-503 plate roll. This readout tracks the position of the back roll for increased accuracy and less waste. Increased safety was also a thought when designing the PR-503. Like all Baileigh Industrial plate rolls, includes dual emergency stop cables that are located on both the front and back of the machine.

The top roll on the PR-503 has a very simple release mechanism to release work that has been wrapped around the top roll. The PR-503 plate roll also has an optional coning attachment for creating conical bends without marring the frame of the roller. Baileigh Industrial's PR-503 plate bending roll uses a simple and rugged design, offering the medium to small fabricator years of quality service.

Specifications:

Part Number PR-503
Stock Number BA9-1006531
Forming Width 61"
Roll Speed 5 rpm.
Upper Roll Dia. 7"
Roll Adjustment Back Hydraulic
Minimum Forming Dia 10.500"
Motor 5 hp
Power 220V / 3-phase
Shipping Weight 6,380 lbs.
Shipping Dimensions 98" x 36" x 56"
