Baileigh Desktop CNC Engravers

Brand:

(No reviews yet) Write a Review

Baileigh

Baileigh Desktop CNC Engravers

DEM-0906 Desktop CNC Engraver - BA9-1022102

The DEM-0906 is a small, lightweight, and portable desktop CNC engraver that is not only for small woodworking projects but also for acrylic and ABS lithophane, EVA foam, and Styrofoam, modeling wax, plastic, and soft metals. It's able to carve products like tooling boards, toolboxes, tiny ornaments, and other miscellaneous projects.

The DEM-0906 portable CNC engraver comes with software, and tooling — often not included with competing tables that cost more. Built to last and the router arrives fully assembled.

  • 12.6" x 5.9" table.
  • This desktop CNC engraver is recommended for signmakers and hobbyists.
  • Powerful 150-watt DC Brushless Motor.
  • Up to 20,000 rpm variable spindle speed.
  • Runs on 110v power.
  • Easy-to-learn design software; just install it onto your computer and start creating patterns.
  • Upload your design file to the table via a USB drive, then use the convenient handheld controller to move the spindle.
  • Stepper motors move the spindle at a maximum speed of 98.43" per minute.
  • Belt-driven X, Y, and Z-axis movement for accurate positioning.
  • 4 T-slotted clamps fit on the table to hold the material down for clean cuts.
  • Laser engraver ready, (sold separately)
  • The structurally strong extruded aluminum table won’t buckle under material weight or spindle pressure.
  • The table ships pre-built with correct alignment for a fast and simple set-up—just an hour or so to uncrate the table and get started with the software.
  • This desktop engraver is covered by a 1-year parts warranty.
  • Lifetime technical support by phone: you can call Baileigh's experienced reps whenever you have a question or need troubleshooting.

Specifications:

Part Number DEM-0906
Stock Number BA9-1022102
Shipping Weight 42 lbs
Special Notes Laser Engraver Ready, Sold Separately
Actual Working Area 8.66" x 6.3"
Speeds 0 - 20,000 rpm (Variable)
Z Axis Stroke 2.48"
Maximum Moving Speed (Inches Per Minute) 98.43
Maximum Engraving Speed (Inches Per Minute) 98.43
Reposition Accuracy .001"
Tool Diameters 4.0 mm
Power 110V
Length 15.36"
Width 15.75"
Height 16.73"
Weight 33 lbs
Table Style T-Slot
Max. Table Load 6.61 lbs
Notes Includes Power Cord, USB 2.0 Cable, Controller, Allen Key_2.5mm & Spare Socket Screw, Silicone Mat, Tungsten Carbide Tool, Clamp set ( big x 2 pcs, small x 2 pcs ), Support Board
Shipping Dimensions 22" x 21" x 21"



DEM-1717 Desktop CNC Engraver - BA9-1022103

The DEM-1717 is a tabletop CNC router that is not only for small woodworking projects but also for acrylic, ABS lithophane, EVA foam, Styrofoam, modeling wax, plastic, and soft metals. It's able to carve products like tooling boards, toolboxes, tiny ornaments, and other projects. This DEM-1717 small CNC engraving machine has also been used as teaching equipment in various high schools and colleges worldwide.

The DEM-1717 tabletop CNC router comes with software and tooling — often not included with competing tables that cost more. Built to last and the router arrives fully assembled.

  • 17" x 17" small CNC engraving machine.
  • Recommended for sign-makers, and hobbyists.
  • Powerful 200-watt DC Brushless Motor.
  • Up to 20,000 rpm variable spindle speed.
  • Runs on 110v power.
  • Easy-to-learn software; just install it onto your computer and start working.
  • Upload your design file to the table, then use the convenient handheld controller to move the spindle.
  • Stepper motors move the spindle at a maximum speed of 98.43" per minute.
  • Belt Drive X, Y, and Z-axis movement for accurate positioning.
  • ER-11 – 4.0 mm tooling diameters.
  • 4 T-slotted clamps fit on the table to hold the material down for clean cuts.
  • Laser engraver ready, (sold separately)
  • The structurally strong extruded aluminum table won’t buckle under material weight or spindle pressure.
  • The table ships pre-built with correct alignment for a fast and simple set-up—just an hour or so to uncrate the table and get started with the software.
  • Covered by a 1-year parts warranty.
  • Lifetime technical support by phone: you can call Baileigh's experienced reps whenever you have a question or need troubleshooting.

Specifications:

Part Number DEM-1717
Stock Number BA9-1022103
Shipping Weight 83 lbs
Special Notes Laser Engraver Ready, Sold Separately
Actual Working Area 12" x 12"
Speeds 0 - 20,000 rpm
Z Axis Stroke 4"
Maximum Moving Speed (Inches Per Minute) 98.43
Maximum Engraving Speed (Inches Per Minute) 98.43
Reposition Accuracy .001"
Tool Diameters ER-11 – 4.0 mm
Power 110V
Length 21.26"
Width 20.87"
Height 20.87"
Weight (lbs) 75 lbs
Table Style T-Slot
Notes Includes Power Cord, USB 2.0 Cable, Controller, Allen Key_2.5mm & Spare Socket Screw, Silicone Mat, Tungsten Carbide Tool, Clamp set ( big x 2 pcs, small x 2 pcs ), Support Board
Shipping Dimensions 22" x 21" x 21"



DEM-2720 Desktop CNC Engraver - BA9-1022104

The DEM-2720 desktop CNC router table comes with software, and tooling — often not included with competing tables that cost more. Built to last and the router arrives fully assembled.

  • 25.5" x 35.5" table.
  • Recommended for sign-makers, and hobbyists.
  • Powerful 200 watt DC Brushless Motor.
  • Up to 20,000 rpm variable spindle speed.
  • Runs on 110v power.
  • Easy-to-learn design software; just install it onto your computer and start creating patterns.
  • Upload your design file to the table via a USB drive, then use the convenient handheld controller to move the spindle.
  • Stepper motors move the spindle at a maximum speed of 98.43" per minute.
  • Lead screw X, Y, and Z axis movement for accurate positioning.
  • ER-11 – 4.0 mm tooling diameters.
  • 4 T-slotted clamps fit on the table to hold the material down for clean cuts.
  • Laser engraver ready (Sold Seperately)
  • Structurally strong extruded aluminum table won’t buckle under material weight or spindle pressure.
  • The desktop CNC router table ships pre-built with correct alignment for a fast and simple set-up—just an hour or so to uncrate the table and get started with the software.
  • Covered by a 1-year parts warranty.
  • Lifetime technical support by phone: you can call Baileigh's experienced reps whenever you have a question or need troubleshooting.

Specifications:

Part Number DEM-2720
Stock Number BA9-1022104
Shipping Weight 155 lbs
Special Notes Laser Engraver Ready, Sold Separately
Actual Working Area 20" x 30"
Speeds 0 - 20,000 rpm
Z Axis Stroke 4"
Maximum Moving Speed (Inches Per Minute) 98.43
Maximum Engraving Speed (Inches Per Minute) 98.43
Reposition Accuracy .001"
Tool Diameters ER-11 – 4.0 mm
Power 110V
Length 31.5"
Width 39"
Height 21.6"
Table Style T-Slot
Shipping Dimensions 48" x 45" x 34"
