Atlas Air Powered 5C Stationary Dead Length Collet Chuck

Brand:

Call for Pricing

(No reviews yet) Write a Review

Atlas Workholding

Atlas Air Powered 5C Stationary Dead Length Collet Chuck


Used on pallets, tombstones, machining centers, standard mills and drill presses: Series ATL225-5C


Features:

  • Powered by air
  • Small foot print
  • Low cost
  • Easy to install
  • High accuracy less than 0.005mm TIR
  • Repeats on duplicate parts +/- 0.008mm
  • Dead length design
  • For best accuracy use high quality Crawford Collets
  • Lever or foot pedal actuated
  • Low maintenance with oil mist lubrication system
  • High resistance to coolant and chip penetration
  • Low maintenance, long life


Specifications:

Item Number ATL225-5C
Collet Type 5C Collets
Max. RPM 4000
Air Pressure 3-8 kg/cm2 (42-114 psi)
Through Hole Dia 26mm (1.02")
Chuck Weight 9.4 kg (20.7 lbs.)
Grip Force 13,000 lbs. @ 100 psi
