Palmgren 24" Disc Finishing Machine - 9681313

Brand:

(No reviews yet) Write a Review
SKU:
9681313

Palmgren

Palmgren 24" Disc Finishing Machine - 9681313


Palmgren's 24" high performance disc finishing machine is built to handle general purpose to precision finishing applications. Medium to large parts are finished fast and effectively. The increased area of contact improves stock removal and finish on all types and sizes of workpieces.


Features:

  • Production duty motor effectively finishes all types of materials
  • Direct drive design with oversized drive shaft and sealed bearings
  • Fully enclosed adjustable guarding
  • Adjustable table - adjusts up and down and angles for precision finishing of both plain and compound miters
  • Safety electrical system: white power on light, green machine running light, drum start/stop switch, on/off push button power switch with keyed lock-out, emergency stop button with electronic brake and 24 volts at all switches
  • 3" dust collection port
  • Fully machined and balanced disc runs true and vibration free
  • Disc is mounted directly to an oversized motor shaft for maximum power and efficiency
  • Precise and ideal for larger workpieces
  • Can grind, deburr, contour and finish workpieces made of metal, wood or plastics
  • Heavy duty steel floor stand with hinged door, internal storage and anti-vibration foot pads


DIMENSIONS: 27.5" L x 31.5" W x 53.5" H


Specifications:

Item # 9681313
Horse Power 4 HP
Volts 230
Phase 3
Amps 11.8
Motor Speed (RPM) 1185
Disc Size 24"
Disc Speed (SFPM) 7425
Table Size 25.5" x 9"
Table Tilt + 90 deg
Weight 300 lbs.


Optional Accessories:

9681320 24" Abrasive Disc
36 Grit / Aluminum Oxide
9681321 24" Abrasive Disc
60 Grit / Aluminum Oxide
9681322 24" Abrasive Disc
80 Grit / Aluminum Oxide



Click to order Optional Accessories for the Palmgren 24" Disc Finishing Machine

24" Disc Finishing Machine
