Sine System-Magnetic Sine Plates-Standard Pole - 77-215-2

Brand:

(No reviews yet) Write a Review
SKU:
77-215-2
Center Distance of Rolls:
20" within .0004"
Dimensions:
24 x 12 x 6-5/8"
Sine System:
2
  • Made in U.S.A.
  • Permanent, ceramic magnetic chucks for superior holding power. Never lose their strength.
  • Same outstanding features as described under the Bolt-On Permanent Magnetic Chucks.
  • 0 - 60° capacity.
  • Minute angle step .200" built into the gage block roll. Eliminates steps in base plate.
  • Two hardened and ground side rails and one locking strap included in all sine system models.
  • Large hinge pins for extra strength.
  • One back rail, one end rail plus 4 mounting bolts included.
  • On all sine system models, identified 0, 1 and 2 the magnetic chuck can conveniently be removed and replaced, offering individual use of the sine plate as well as the magnetic parallel chuck.
For Holding Large and Thick Work Pieces
