Suburban SineSet Sine Plate SP-2412-S2, 24" x 12" x 4" - 77-035-4

Brand:

(No reviews yet) Write a Review
SKU:
77-035-4
SineSet Series:
S2
C:
20" ±0.0004"
L x W x H:
24" x 12" x 4"
Square and Parallel:
0.0005"
Weight:
267 lbs.

Suburban Tool

Suburban SineSet Sine Plate SP-2412-S2
24" x 12" x 4"

  • Made of steel, hardened to Rc 58-60.

  • Sizes up to 6" x 6" have 1/4-20 tapped holes, larger sizes have 3/8-16 tapped holes. Model number SP-555 has T-slots for 1/4" T-bolts.

  • Gage block roll has two 0.200" minute steps for setting small angles with standard gage block sets.

  • Models with the suffix "S0, S1 or S2" are part of the SineSet® System. Other products with the same part number suffix will bolt directly to these sine plates (Click here to see Compatibility Chart).

  • A locking strap that always remains below the top surface and two self-storing, hardened & ground rails are standard.




See all Suburban SineSet Sine Plates

Sine Plate SP-2412-S2
