Mitutoyo Offset Centerline Caliper, 0.4-12" / 10-300mm - 573-708

Brand:

(No reviews yet) Write a Review
SKU:
573-708
Accuracy:
+- .0015"
Range:
0.4 - 12" / 10-300mm
Resolution:
.0005" / 0.01mm
Mass (g):
320

Mitutoyo

Mitutoyo Offset Centerline Caliper, 0.4-12" / 10-300mm - 573-708


Features:

  • IP67
  • Specially designed for center to center distance measurements on the same and offset planes
  • Can also measure from edge to center
  • Hole diameter should be in the range of 1.5mm-10mm (.06"-.4")
  • With SPC data output. (series 573)
  • Supplied in fitted plastic case


Technical Data:

  • Accuracy: Refer to the list of specifications.
  • Resolution: 0.01mm or .0005"/0.01mm
  • Graduation: 0.05mm
  • Display: LCD
  • Length standard: ABSOLUTE electrostatic capacitance type linear encoder
  • Max. response speed: Unlimited
  • Battery: SR44 (1 pc.), 938882
  • Battery life: Approx. 3.5 years under normal use


Function of Digital Model

  • Origin-set, Zero-setting, Power On/Off, Data output, inch/mm conversion (inch/mm models)
  • Alarm: Low voltage, Counting value composition error


Optional Accessories for Digital Model:

  • 05CZA624: SPC cable with data switch (1m/40")
  • 05CZA625: SPC cable with data switch (2m/80")
