Mitutoyo Linear Height Gage LH-600E/EG, Series 518 with Master Grip - 518-352A

Brand:

(No reviews yet) Write a Review
SKU:
518-352A

Mitutoyo

Mitutoyo Linear Height Gage LH-600E/EG, Series 518 with Master Grip - 518-352A

High Performance 2D Measurement System


Features:

  • Excellent accuracy of (1.1+0.6L/600)μm with 0.1μm/0.5μm resolution/repeatability
  • Perpendicularity (frontal) of 5μm and straightness of 4μm are guaranteed
  • Pneumatic full/semi-floating system allows adjustment of air-cushion height
  • Basic statistical functions are provided and, additionally, RS-232C / USB data output provides the option of evaluating measurement data externally with SPC software on a PC
  • One-key operation for running a semi-automatic measurement
  • Data entry from a Digimatic tool


Technical Data:

  • Measuring range: 0 - 38" / 0 - 972mm
  • Slider stroke: 24" / 600mm
  • Resolution: 0.0001 / 0.001 / 0.01 / 0.1mm or (switchable)
    0.0001 / 0.001 / 0.01 / 0.1mm / .000001” / .00001” / .0001” / .001”
  • Accuracy at 20°C: Refer to the list of specifications.
  • Floating method: Full / semi-floating with built-in air compressor
  • Display:TFT LCD (color)


Specifications:

Order Number 518-351A-21
Measuring Range 0-38" / 0-972 mm
Resolution .000001/.00001/.0001/.001/in 0.0001/0.001/0.01/0.1mm
Measuring Accuracy .000043 + (.000024 x L*/24)in/(1.1+0.6L**/600)µm
Repeatability Plane:.000015/0.4µmBore:.000035in0.9µmin µm
Perpendicularity .0002in 5µm
Drive Method Motor Drive (5,10,15,20,25,30,40mm/s=7steps)/manual
Measuring Force 1N
Balance Method Counter balance
Main Unit Floating Method Full/semi-floating with air
Air Source Built-in air compressor
LCD Display TFT LCD (color)
Language for Display English/German/French/Spanish/Italian/Japanese
Number of Datas 60000 1 program 30,000(max)
Power Supply AC Adapter/Battery (Ni-MH)
Power Consumption 43VAW
Operation Time Approx. 5 hours
Mass 52.8 lbs / 24 kg
