Mitee-Bite 16mm Press Fit Pin - 38760

Brand:

(No reviews yet) Write a Review
SKU:
38760
A:
19mm
B:
12.7mm
C:
13mm
D:
6.35mm
E:
M8x1.25
F(+/-) .000/.001″(.000/.025mm):
16.00mm
G*:
12mm


Mitee-Bite 16mm Press Fit Pin - 38760


Pins are intended for press fit or close tolerance removable slide fit applications. Install in a precision bore or a bushing with the center threaded for the Tapered screw. If precise location is not necessary, pin can be used on top of fixture plate. Mitee-Bite provides a simple tool to make Installation and Removal (I/R) of the XYZ Pins quick and easy. Note: If recessing pin into fixture beyond slits be sure to provide clearance for expanding segments.

*G – Minimum diameter pin can be machined or turned down to
** Set includes screws (2) SHCS



See all Mitee-Bite Press Fit Pins

16mm Press Fit Pin
