Mitutoyo Screw Thread Micrometer, Digital 0-1"/0-25.4mm - 326-351-10

Brand:

(No reviews yet) Write a Review
SKU:
326-351-10
Range:
0 - 1" / 0 - 25.4 mm
Accuracy:
±0.0002"

Mitutoyo

Mitutoyo Screw Thread Micrometer, Digital 0-1"/0-25.4mm - 326-351-10

# 326-351-10 / 326-351-30


Features:

  • IP65 water/dust protection (Series 326)
  • 60 degree or 55 degree V-anvil and conical spindle (interchangeable) are optional, which are made of high-grade steel, hardened and precision ground
  • With Ratchet Stop for constant force
  • With SPC output (Series 326)
  • With a standard bar except 0-25mm / 0-1 in model
  • Suplied in fitted plastic case


Technical Data:

  • Resolution*: 0.001mm or .00005"/0.001mm
  • Graduation**: 0.01mm or .001"
  • Spindle feed error: 3µm/.00012”
  • Display*: LCD
  • Battery*: SR44 (1 pc.), 938882
  • Battery life*: Approx. 1.2 years under normal use
  • Dust/Water protection level*: IP65

* Digital models
** Analog models


Function of Digital Model:

  • Zero-setting, Data hold, Data output, 2 Presets, Function lock.
  • inch/mm conversion (inch/mm models)
  • Alarm: Low voltage, Counting value composition error


Optional Accessories for Digital Models:

  • 05CZA662: SPC cable with data switch (1m / 40")
  • 05CZA663: SPC cable with data switch (2m / 80")



See all Mitutoyo Screw Thread Micrometers, Series 326, 126 - Interchangeable Anvil-Spindle Tip Type

Screw Thread Micrometer - Digital, Less Anvils
