Mitutoyo Micrometer Head, 0-50mm - 197-101

Brand:

(No reviews yet) Write a Review
SKU:
197-101

Mitutoyo

Mitutoyo Micrometer Head, 0-50mm - 197-101

Series 197


Features:

  • Large thimble micrometer head with non-rotating spindle.
  • Floating thimble allows easy zero setting at any spindle position.
  • Bidirectional graduation for easy reading in both directions.
  • Dual-spindle mechanism for quick feeding of 1mm/rev.
  • Carbide tipped measuring face.


Technical Data:

  • Graduations: 0.005mm or .0002"
  • Spindle pitch: 1mm
  • Spindle face: Flat with carbide tip (more than HRA90), lapped surface
  • Scale surface: White anodized aluminum


Specifications:

Item Number 197-101
Type Metric
Range 0 - 50 mm
Accuracy ± 5µm
Stem Diameter 18 mm
Stem/Spindle face Plain/Flat(carbide tip)
Remarks Bidirectional graduation



See all Mitutoyo Micrometer Heads Series 197

Mitutoyo Micrometer Head, 0-50mm
