SPI Ultrasonic Thickness Gage 15-145-6
A hand held microproccessor-controlled thickness gage specifically designed for measuring metalic and non-metalic materials such as steel, aluminium, titanium, plastics, ceramics, gleaa and any other good ultrasonic wavw-conductor with paraller top and bottom surfaces.
-
Used in many areas of industry
-
Extremely easy to use
-
Can perform precise measurements on vatious types of raw materials, component parts and assembled machinary
-
Can also be used to moniter all types of pipes and pressure vessels for loss of thickness due to corrosion or erosion
-
After a simple calibration to a known thickness or sound velocity, the gage will have accurate readings in inches or millimeters.
-
Includes: base unit (w/built-in calibration block), 5 Mhz dual sensor probe, 2 oz. bottle of couplant gel, AAA battery set, operation manual and caring case.
Specification
- Display Type: Large 4-digit LCD
- Min. Diaply Unit: 0.001"/0.1mm
- Measuring range: 0.04 - 8" (0.1 mm - 200 mm) in steel w/standard probe (Other values depending on material)
- 'Low limit Steel pipes: Min Dia. 0.8 x 0.1" (20 x 3 mm)
- Display Accuracy: 0.01"
- Sound Velocity Range: 1640 - 29,527 ft/S (500-9000 m/s)
- Operating Temp: 32º to 122º F (-5 to 40 C)
- Frequency: 5MHz
- Update Range: 4Hz
- Power Supply: 1.5V AAA Alkaline Batteries (4 Pc.)
- Battery Life: Approx: 250 hrs/Battery set
- Dimensions: 4.9 x 2.6 x 0.9" (161 x 69 x 32 mm)
- Weight: 0.7lb
- Operating Current: <20mA (3V)
