MAHR Millimar Inductive Lever-Type Test Indicator 1318
5313180
Inductive probe 1318
Features:
- Dial test indicator inductive probe
- Flexible probe adjustment to contact surface
- Highly robust as the measuring system is offset from the guide and mounting shaft
- Outstanding clamping properties
- Chemical resistance data: resistant to oil, gasoline, water and aliphatics. Moderately resistant to acids, bases, solvents and ozone
Technical Data:
| IP protection category | IP 50 |
| Measuring range from | -0.3 mm |
| Measuring range up to | 1 mm |
| Distance of lower stop MAX | -0.37 mm |
| Distance of upper stop MAX | 1.6 mm |
| Measuring force | 0,25 N +/- 0,05 N |
| Increase in measuring force | 0,04 N/mm |
| Sensitivity deviation | 0.50% |
| Repeatability fw (µm) | 0.03 µm |
| Hysteresis fu (µm) | 0.5 µm |
| Linearity deviation within +/- 0,3 mm | 0.9 µm |
| Cable length | 1.5 m |
| Compatibility | Mahr LVDT |
