Baileigh DP-2012F-HD-V3 Floor Drill Press - BA9-1015771
Need more capacity from your drill press, well look at the DP-2012F-HD-V3 floor drill press to see if it will fit your needs. This mammoth has a 20" swing and a cast iron 16.5" x 18.5" oversized table and can handle just about anything that you can throw at it. The 3.6" diameter column and 24" x 16.5" cast iron base make for one rigid structure.
The DP-2012F-HD-V3 uses 220 volt single phase power to turn its MT4 spindle to 3200 rpms. The range of speeds is done through the use of six pulleys that give the DP-2012F-HD-V3 12 spindle speeds. It also includes a drill chuck that can opens to a maximum of 3/4".
Specifications:
| Part Number | DP-2012F-HD-V3 |
| Stock Number | BA9-1015771 |
| Spindle Speeds | 12 - 220 to 3200 rpm |
| Distance from Spindle to Table | 26" |
| Distance from Spindle to Base | 46.75" |
| Shipping Weight | 390 lbs |
| Table Size (Length) | 16.5" |
| Table Size (Width) | 18.5" |
| Swing | 20" |
| Spindle | MT4 |
| Drill Capacity | 1.25" |
| RPM | 150-4200 |
| Spindle Travel | 4.75" |
| Drill Chuck Capacity | 1/32" - 5/8" (JT3 key) |
| T-Slot Size | 3 @ 5/8" |
| Power | 220V Single Phase |
| Length | 35.4" |
| Width | 25.6" |
| Height | 66.7" |
| Horse Power | 2 hp |
| Weight | 259 lbs |
| Shipping Dimensions | 69" x 44" x 24" |
Baileigh DP-2012F-HD-V3 Floor Drill Press
