Baileigh DP-0625E Belt Driven Metal Drill Press, 5/8" Capacity Mild Steel - BA9-1022127
This economical belt driven drill press runs smoothly even at full capacity - this 14" drill press lets you run tooling at the proper speed to fit your application with its 5 speed pulley configuration which helps extend tooling life.
- .5 hp motor requires 110 volt power and will work at any shop or site.
- Belt driven head drills a maximum capacity of 5/8" steel.
- 5 speeds in the range from 250 to 2900 rpm to suit your application.
- 2-7/8" steel column eliminates flexing even when drilling at full capacity.
- Rigid cast iron base and table add strength to the drill’s structure.
- Includes a safety shield around the drill head to protect you.
- Baileigh backs this drill press machine with a 1-year parts warranty
Specifications:
| Part Number | DP-0625E |
| Stock Number | BA9-1022127 |
| Spindle Speeds | 5 |
| Swing | 14" |
| Diameter of Column | 2-7/8" |
| Base Size | 25-3/4" x 16-1/2" |
| Table Size | 11" x 11" |
| Quill Diameter | 1-3/4" |
| Spindle Nose to Table | 6” Min to 36" Max |
| Spindle Nose to Base | 48" |
| Spindle Taper | B16 |
| Table Angle Adj | 360° |
| Main Motor | 1/2 hp |
| Rpm | 250, 700, 1150, 1900, & 2900 |
| Drill Capacity Steel | 5/8" |
| Power | 110 Volt |
| Shipping Weight | 240 lbs. |
| Special Notes | Includes B-16 1-16mm Keyless Chuck |
| Shipping Dimensions | 69" x 44" x 23" |
           Baileigh DP-0625E Belt Driven Metal Drill Press, 5/8" Capacity Mild Steel
