NOGA Indicator Holder with Double Fine Adjustment NF6160
- Double fine adjustment.
- Bottom: unique single direction
- Top: universal swivel clamp
- Holds 6mm, 8mm, 3/8", dovetail and back lug.
- Unique central locking mechanism with Noga designed spring loaded bearing.
- Instantly fastens in any position.
- Fast and easy to set up gauges into required position.
- Aluminum material with black finished arms.
- 5 axis holder.
* Note: Indicator Not Included.
Specifications:
| BRAND | NOGA |
| MODEL # | NF6160 |
| BOTTOM ARM LENGTH | 2.20" |
| TOP ARM LENGTH | 2.01" |
| HOLDS STEM DIAMETER | 6mm, 8mm, 3/8", dovetail & back lug |
| HOLDING POWER | 70 lbs. |
| FINE ADJUSTMENT | Top & Bottom |
| TYPE | Articulating Arm |
| APPLICATION | Easy to set up gages into required position. |
| BASE DIMENSIONS | 1.58" x 1.18" x 1.38" |
| TOTAL ARM LENGTH | 4.21" |
| WEIGHT | 1.20 lbs. |
| COUNTRY OF ORIGIN | ISRAEL |
Indicator Holder with Double Fine Adjustment NF6160
