SPI Electronic External Caliper Gage, 0.4 - 1.2" - 14-290-1
Suited for measuring outside diameters, grooves, and other hard to reach outside dimensions.
Features:
- Digital resolution: 0.0005"/0.01 mm
- Analog resolution: 0.0005", 0.001", 0.0002"
0.01, 0.02, 0.05 mm - Analog display: ±20 graduation
- Accuracy: 0.0012"/0.03 mm
- Contact point: 1/16" radius chisel x 0.200" wide
- Inch/metric conversion
- Preset origin for abslolute measurement
- Origin data recall
- Absolute and incremental measurement
- Dial rotates ±170 degrees
- Auto power off
- Furnished in aluminum attaché
- Certificate of calibration traceable to NIST
- D.O.T. Regulated. Shipped via ground freight only.
Specifications:
| Type | External Caliper Gage |
| Minimum Measuring Range (Inch) | .4000" |
| Minimum Measuring Range (mm) | 10.00 mm |
| Maximum Measuring Range (Inch) | 1.2000" |
| Maximum Measuring Range (mm) | 30.00 mm |
| Resolution | .0005" |
| Ball Diameter | .0600" |
| Gagging Depth | 3.15" |
| Data Output | Yes |
| Groove Width | 0.256" |
| Accuracy | 0.0012" |
| Battery Type | CR2032 |
| Includes | Certificate of Calibration Traceable to NIST |
| SPI Part Number | 14-290-1 |
SPI Electronic External Caliper Gage
